FDCA125VNX-W/1 CONTROL AND PARTS SET

FDCA125VNX-W/1 CONTROL AND PARTS SET

Parts List

Key:
Instock.
Nilstock.
Contact MRE.

Check the parts position number [ ] matching with the drawing. Login to view prices.

[1] In Stock
PCA505A377BT
PWB ASSY (CONTROL)
Notes: ONLY FOR SUPPLY PARTS PWB1, PWB1 - CONTROL BOARD
[1-28] Contact
PCA501A197F
CONTROL UNIT
Contact
Substitute: NOT AVAILABLE Notes: ?, NOT AVAILABLE
[2] In Stock
PCA505A194DK
PWB ASSY(INV.)
Notes: ONLY FOR SUPPLY PARTS PWB2, PWB2-INVERTER BOARD
[3] In Stock
PCA505A179J
PWB ASSY(N.F)
Notes: ONLY FOR SUPPLY PARTS PWB3, NOISE FILTER (SCREWS NOT INCLUDED) Show Image
PCA505A179J
[4] In Stock
PCA505A180
DRED
Notes: ONLY FOR SUPPLY PARTS PWB4, THIS PWB IS ONLY REQUIRED IN SPECIAL CIRCUMSTANCES, FOR MORE INFO CONTACT TECH SUPPORT Show Image
PCA505A180
[5] In Stock
SSA551A192L
SENSOR
Notes: THO-AF, THO-IPM THO-TR THO-AF Show Image
SSA551A192L
[6] In Stock
PSA551A014P
SENSOR ASSY
Notes: THO-A,S,D,R1, THO-A,S,D,R1 - WHITE PLUG WITH 6 BLACK WIRES AND 2 YELLOW WIRES Show Image
PSA551A014P
[7] In Stock
PSA551A013J
SENSOR
Notes: THO-R2 Show Image
PSA551A013J
[8] In Stock
SSA554B092
REACTOR
Notes: L1
[9] In Stock
SSA552F601
CAPACITOR
Notes: C1, 450v 2700mf, COMPRESSOR CAPACITOR Show Image
SSA552F601
[10] In Stock
SSA561B693AC
BLOCK,TERMINAL
Notes: TB Show Image
SSA561B693AC
[11] In Stock
SSA555A662
DIODE
Notes: DIODE STACK/DIODE MODULE/DIODE BRIDGE Show Image
SSA555A662
[12] In Stock
PCA504A300
FUSE ASSY
Notes: F 30A, 30AMP FUSE WITH SOLDED WIRES (FOR FUSE HOLDER SEE SSA564B044)
[13] In Stock
SSA564B044
HOLDER, FUSE
Show Image
SSA564B044
[14] In Stock
SSA556J035A
IC (ACTIVE CONVERTER)
Notes: A/F MODULE (Active Filter Module)
[15] Contact
S750W30
GROMMET
Contact
Notes: f35, D35
[16] In Stock
SSA554D183
KILLER,NOISE
Show Image
SSA554D183
[17] Contact
PCA504A292C
WIRING ASSY
Contact
Notes: PWB1 CNDRAM- PWB4 CNDRAM, PWB1 CNDRM- PWB4 CNDRM
[18] In Stock
PCA504A264GA
WIRING ASSY
Notes: PWB1 CNI1- PWB2 CNI2 Show Image
PCA504A264GA
[19] In Stock
PCA504A292V
WIRING ASSY
Notes: PWB3 CN1- TB 1,TB 2 Show Image
PCA504A292V
[20-22] Contact
PCA504A292P
WIRING ASSY
Contact
Notes: PWB3 L1o,PWB3 No- PWB1 CNW, PWB4 CNPOWER, PWB3 L1o,PWB3 No- PWB1 CNW,PWB4 CNPOWER
[21] In Stock
SSA564A149AG
FUSE(CURRENT)
Notes: F 4A, F 4A‚ - 4 AMP FUSE - ****NOT MAIN FUSE**** Show Image
SSA564A149AG
[22] In Stock
RWC564B002
HOLDER,FUSE
Show Image
RWC564B002
[23] In Stock
PCA504A264FB
WIRING ASSY
Notes: PWB1 CNI3- PWB2 CNI4, PWB1 CNI3-PWB2 CNI4
[24] In Stock
PCA504A264HC
WIRING ASSY
Notes: PWB2 CNACT1- LACT CNACT, 4 black wires with white plugs PWB2-ACTIVE FILTER MODULE. One plug is slightly smaller than the other. (PWB2 CNACT1- LACT CNACT)/ LENGTH 55.5CM Show Image
PCA504A264HC
[25] In Stock
PCA504A292Z
WIRING ASSY
Notes: C1 +,C1 -- PWB1 CNA1,PWB1 CNA2
[26] Contact
PCA142A174F
PLATE,CONTROL
Contact
[27] Contact
PCA142A134P
PLATE,CONTROL
Contact
[28] Contact
PCA142A132J
PLATE,CONTROL
Contact
[29] In Stock
RKJ941F001
SPRING LEAF
Notes: FOR THO-R1,R2,D,S Show Image
RKJ941F001
[30] Contact
PSC011G564AJ
LABEL,WIRING
Contact
Notes: ?
[31] Contact
PSB011F362C
LABEL,MODEL NAME
Contact
Notes: ?
SKU: FDCA125VNX-W/1 CONTROL AND PARTS SET Category:
